Home > O-ring, Seal Design > Static Seals > Axial-Static Glands
Static Seal Gland Dimensions
Axial-Static Glands
|
Measurements
in inches
|
 |
Measurements
in millimeters
|
||||||||||
|
Size
|
W
|
Depth
|
Comp.
|
Width
|
Fill
|
Radius
|
Radius
|
Width
|
Depth
|
W
|
Size
|
|
|
AS
568
|
0.070
|
0.048
|
31%
|
0.095
|
109%
|
0.010
|
0.25
|
2.41
|
1.22
|
1.78
|
AS
568
|
|
|
-000
|
±
.003
|
±
.002
|
±
6%
|
±
.005
|
±
19%
|
±
.005
|
±
.13
|
±
.13
|
±
.05
|
±
.08
|
-000
|
|
|
AS
568
|
0.103
|
0.076
|
26%
|
0.145
|
97%
|
0.010
|
0.25
|
3.68
|
1.93
|
2.62
|
AS
568
|
|
|
-100
|
±
.003
|
±
.004
|
±
6%
|
±
.005
|
±
14%
|
±
.005
|
±
.13
|
±
.13
|
±
.10
|
±
.08
|
-100
|
|
|
AS
568
|
0.139
|
0.105
|
24%
|
0.185
|
100%
|
0.018
|
0.46
|
4.70
|
2.67
|
3.53
|
AS
568
|
|
|
-200
|
±
.004
|
±
.005
|
±
6%
|
±
.005
|
±
13%
|
±
.008
|
±
.20
|
±
.13
|
±
.13
|
±
.10
|
-200
|
|
|
AS
568
|
0.210
|
0.170
|
19%
|
0.285
|
91%
|
0.028
|
0.71
|
7.24
|
4.32
|
5.33
|
AS
568
|
|
|
-300
|
±
.005
|
±
.005
|
±
4%
|
±
.005
|
±
9%
|
±
.008
|
±
.20
|
±
.13
|
±
.13
|
±
.13
|
-300
|
|
|
AS
568
|
0.275
|
0.225
|
18%
|
0.375
|
90%
|
0.028
|
0.71
|
9.53
|
5.72
|
6.99
|
AS
568
|
|
|
-400
|
±
.006
|
±
.005
|
±
4%
|
±
.005
|
±
7%
|
±
.008
|
±
.20
|
±
.13
|
±
.13
|
±
.15
|
-400
|
|
|
B2401
|
0.122
|
0.093
|
24%
|
0.162
|
80%
|
0.018
|
0.46
|
4.12
|
2.36
|
3.10
|
B2401
|
|
|
G-
|
±
.004
|
±
.005
|
±
7%
|
±
.005
|
±
12%
|
±
.008
|
±
.20
|
±
.13
|
±
.13
|
±
.10
|
G-
|
|
|
GB2401
|
0.224
|
0.181
|
19%
|
0.304
|
72%
|
0.028
|
0.71
|
7.72
|
4.61
|
5.70
|
B2401
|
|
|
G-
|
±
.006
|
±
.005
|
±
4%
|
±
.005
|
±
7%
|
±
.008
|
±
.20
|
±
.13
|
±
.13
|
±
.15
|
G-
|
|
Note: Gland diameter should provide for no greater than 3% to 5% stretch (based on nominal O-ring ID).
